Freud Diablo Composite Material/Plastics
Composite-Plastics Cutting
Specially formulatedTiCo™ Hi-Density carbide to maximize cutting life in composite decking materials and plastics
Modified Triple Chip Grind (MTCG) enables the material to remain cool while cutting for melt-free cuts
Laser cut stabilizer vents keep the blade straight and true for superior quality cuts and no swirl marks
Diablo’s TrexBlade is the only recommended composite decking by Trex Company when cutting composite decking materials. These new blades deliver maximum performance and highest quality of finish; making it a ‘must-have’ tool for both professionals and DIYers planning composite decking projects. Diablo’s new saw blade series has a modified triple chip tooth grind design, Perma-SHIELD® non-stick coating, and specific TiCo™ Hi-Density carbide to deliver more efficient and cleaner cuts with no swirl marks, less “gumming” of blade teeth and longer cutting life .
Specially formulatedTiCo™ Hi-Density carbide to maximize cutting life in composite decking materials and plastics
Modified Triple Chip Grind (MTCG) enables the material to remain cool while cutting for melt-free cuts
Laser cut stabilizer vents keep the blade straight and true for superior quality cuts and no swirl marks
Thin Kerf design requires less cutting power, making them ideal for underpowered saws at the jobsite
Perma-SHIELD Non-stick coating reduces drag and shield s the blade against heat, gumming and corrosion
Ideal For: High quality finish cuts in composite material and cellular PVC
Suggested Projects: Siding/Decking
TECHNICAL SPECIFICATIONS:7-1/4″
ARBOR 5/8″
DIAMETER 7-1/4″
HOOK ANGLE -3°
KERF.065″
PLATE.040″
TEETH 44 MTCG
MAX RPM 10000
TECHNICAL SPECIFICATIONS:10″
ARBOR 5/8″
DIAMETER 10″
HOOK ANGLE -3°
KERF.102″
PLATE.071″
TEETH 72 MTCG
TECHNICAL SPECIFICATIONS:12″
ARBOR 1″
DIAMETER 12″
HOOK ANGLE -3°
KERF.102″
PLATE.071″
TEETH 84 MTCG
MAX RPM 5000
