This thin kerf heavy-duty, non-ferrous metal cutting blade produces an excellent finish. These blades have custom designed gullets to minimize chip build-up and specially formulated carbide for long life. Freud recommends use of a liquid lubricant when cutting. This can be accomplished with a spray of WD-40 or other lubricant every 4 to 5 cuts. Wax sticks are not recommended.
Ideal for cutting medium non-ferrous materials and aluminum. Wall thickness 1/4″ max.
[TABS]
Features
- Premium TiCo HI-Density Carbide Non-Ferrous Blend for Maximum Performance
- Freud-Made TiCo Carbide specifically designed to cut nonferrous metals extends tooth life
- Thin Kerf allows for faster feed rate and reduced waste
- Silver Ice Coating resists corrosion and pitch build-up
Specs
Diameter:10″
Teeth:80
Grind:TCG
Arbor:5/8″
Hook Angle:-5
Kerf:.091″
Plate:.071″
