72732362090, Fein JMC MAGFORCE 90 Compact Magnetic Base Drill
Smallest and lightest magnetic base drill with forward/reverse operation on the market. Access hard-to-reach areas and easily work overhead or vertically.
Features:
- Powerful, maintenance-free 10 A [1,200 W] HighPerformance brushless motor.
- Take on any drilling application with its variable speed and forward/reverse operation.
- Ratcheting handle allows you to work in even the tightest spaces.
- German-engineered to be extremely durable, wear-resistant for drilling in tough applications.
- Work safely: includes tilt sensor safety shutoff, easy to read magnetic holding force display, and personal safety switches.
- User controls are always in view and intuitive to use because each control feels different.
- High gear level for clear view of the hole location.
- Large installation space below the drill spindle with a stroke of 1-13/16 [46] in[mm].
- Drive shaft combined 1/2 in square and 8 mm hexagonal socket.
- Integrated handle.
- “Memory function” speed storage.
- Storage for 5 mm Allen key directly on the tool.
- Inner cooling lubrication with included hand pump.
- Perfectly equipped for any job. Easily transported with our L-BOXX system.
Specifications:
- Power consumption: 1,200 W
- Power output: 680 W
- Full load speed: 130 – 610 rpm
- No load speed: 130 – 660 rpm
- Carbide cutter max. dia.: 1-3/8 [35] in[mm]
- HSS cutter max. dia.: 1-3/8 [35] in[mm]
- Cutter max. drilling depth: 1-3/8 [35] in[mm]
- Twist drill max. dia.: 9/16 [14] in[mm] in[mm]
- Tapping: 3/8″ (M10)
- Max. countersinking dia.: 1-1/4 [32] in[mm]
- Reaming max. dia.: in[mm]
- Cutter holder: 3/4″ Weldon
- Stroke: 1-13/16 [46] in[mm]
- Minimum clearance: 40 mm
- Construction height: 11-7/16″ [290] in[mm]
- Length: 6-5/8″ [169] in[mm]
- Magnetic holding force: 2248 [10,000] lbs[N]
- Magnetic holding force: 10,000 N
- Magnetic base dimensions: 6-7/8 [175] x 3-1/8 [80] in[mm]
- Magnetic base dimensions: 175 x 80 mm
- Cable with plug: 9.8 [3] ft[m]
- Weight: 18.74 [8.50] lbs[kg]
VIBRATION AND SOUND EMISSION VALUES
- Sound pressure level LpA: 95.3 dB
- Sound power level LWA: 103.3 dB
- Peak sound value LpCpeak: 106.3 dB
- Vibration value 1 hv 3-way: ah.D = <2.5 m/s
Includes:
- JMC MAGFORCE 90
- (1) 1/2 in ratchet
- (1) 1/2 in socket wrench extension
- (1) coolant pump
- (1) safety strap
- (1) chip hook
- (1) centering pin 3-1/8″ x 3/16” [80 x 4.75 mm]
- (1) centering pin 3-1/4″ x 1/4″ [82 x 6.35 mm]
- (1) chip guard
- (1) additional handle
- (1) Allen key 5 mm
- (1) hexagonal socket key with T-grip, 5 mm
- (1) plastic carrying case (L-BOXX 238)
