Description:
185080F-01-1,HD CB 80A SW RESET SURFACE MNTSwitchable ResetSingle Pole Thermal Type Breakers• Ratings: 30–150A; 30V DC• Interrupt Capacity: 3000A• Operating Temperature: -25°F (-32°C) to 180°F (82°C)• Storage Temperature: -30°F (-34°C) to 300°F (149°C)• Applications: Auxiliary and accessory circuits – Marine applications, battery chargers and DC audio systems. • Sealed for engine compartment and bilge area applications.• Housing: Thermoset plastic; UL rated 94VO; 311ºF (155ºC).• Stud insulators are provided on covered units with F (Surface Mount) bases;• Tin plated copper studs, brass rivets and stainless steel locking nuts.• Mounting: Panel or surface• Terminal Stud Torque: 50 in-lb (5.6Nm) max.• Indicator: Series 184 & 185 have a unique reset mechanism providing visible indication of tripped condition• Ingress Protection Rating: IP67• Approvals: Complies with SAEJ1625, J1171 and UL1500 (Ignition protected) specifications.
